Description

SPECIFICATION:

1. Operating environment:

T4 temperature, -40~70 ° C;

relative humidity, 0~100% RH;

atmospheric pressure, 86~106 kPa;

Vibration, (10~500) Hz, peak acceleration <19.6m / s2;

External magnetic field of the AC ≤400A/m.

2. Power supply: 3.6VDC, battery capacity: 38Ah.

3. Measurement performance:
Angle, capacity: -45°~+ 45°,

accuracy: 0.5% F.S,

stability: ±0.1% FS / year;

Maximum dynamometer collection point 255, collection period ≥10 minutes, settable; open, stop alarm.

4. Wireless communication:

Transmission distance (empty direct view) ≥ 300m;

RF transmission power ≤ 10mW;

Communication protocol, ZigBee PRO 2007 or SMSF; custom available.

5. Protection level: IP65.

6. Dimensions:

length × width × height = 256 mm × 95 mm × 102 mm (maximum)
